Electric Winch 12000 LBS 6hp 12V Motor Wireless Controller 4X4 Syntheic Rope

Description

1. Unbeatable value for money – reliable affordable and massive 12,000lb of pulling power.

2. 6HP Motor 265:1 Gearbox ratio and handy wired control.

3. NEW MASSIVE 6 HORSEPOWER MOTOR, FASTER, SMOOTHER and STRONGER.

4. NEW 265:1 GEAR REDUCTION RATIO - For more torque and greater pulling power

5. NEW RE-ENGINEERED, UPGRADED BRAKE - Larger surface area for better braking power, to hold the heaviest 4WDs on the steepest tracks.

6. NEW WIRED REMOTE & Wireless - All built into one unit so you'll be in control no matter the situation

7.NEW THICKER 9.5MM SYNTHETIC ROPE - New, stronger Ultra High Molecular Weight Polyethylene rope, lightweight but high strength.

8.PRECISION ENGINEERED - The 3-stage planetary gearbox means smooth and quiet operation over long periods. You'll have to hear it to believe it!

9.TRIED & TESTED - Coming from a long line of winches used all around Australia

10.TOUGH - Built for the punishment that Aussie 4WDers put their gear through everyday

11. 10" x 4.5" BOLT PATTERN

Standard bolt pattern to suit most bullbars or winch cradles - plus easy DIY installation and wiring.

Specifications

Rated Single Line Pull

Rated Single Line Pull	12,000lbs (5,443kgs)
Motor	6hp / 4.5kW Series Wound
Main Body	Sealed
Control	Wired (3.7m detachable lead)
Gear reduction ratio	265:1
Clutch	Keyway Cam
Braking Action	Automatic in the drum
Battery Leads	2 gauge, 1.7m long
Rope	9.5mm X 26m Ultra High Molecular Weight Polyethylene
Dimensions	20.5/8" X 6.1/4" X 7.5/8" (526mm X 160mm X 218mm)
Bolt pattern	10" X 4.5" (254mm X 114.3mm)
Net Weight	37kg
Colour	Black

DC12V Line Speed & AMP Draw (First Layer)

12,000lb Line Pull & Cable Capacity

Layers of cable	1	2	3	4
Rated line pull per layer (lbs/kg)	12,000/ 5,443	9,210/ 4,170	8,030/ 3,640	6,894/ 3,125
Cumulative cable capacity (ft/m)	17/ 5.1	41/ 12.4	72/ 21.7	91.89/ 30
Layers of cable	1	2	3	4
Rated line pull per layer (lbs/kg)	12,000/ 5,443	9,210/ 4,170	8,030/ 3,640	6,894/ 3,125
Cumulative cable capacity (ft/m)	17/ 5.1	41/ 12.4	72/ 21.7	91.89/ 30

Warranty

1 Year Warranty

Notes

FAIRLEAD INCLUDED
